portant;">●可重复使用多次

portant;">●阻力小、风量大

portant;">●广泛运用于空调系统的中级过滤

portant;">●Adopts reusable times

portant;">●Responding to small resistance, air

portant;">●Widely used in air conditioning system of intermediate filtration

portant;">构成材料及运行条件

portant;">Materials and operating conditions

portant;">●框材：铝合金或镀锌板外框

portant;">●External frane：Aluminum alloy steel or frame

portant;">●滤料材质：新型复合无纺布

portant;">●Filter material: new composite nonwoven fabric

portant;">●滤料颜色：F5(白色)45%（浅黄色）、F6(绿色)65%（桔红色）、

portant;">F7(粉红色)85%（紫色）、F8(浅黄色)95%（深黄色）

portant;">●Liao color: The F5 (white) 45% (yellow), F6 (green) 65% (orange),

portant;">F7 (pink) 85% (purple), F8 (yellow) 95% (deep yellow)

portant;">●密封条：醋酸乙酯

portant;">●Gasket：EVA

portant;">●使用温度、湿度：80℃、80%以内

portant;">●Use the highest temperature, humidity：80℃、80%

portant;">型号尺寸及其他参数

portant;">Standard specification

型号 model	外形尺寸 Outside Dimensions (mm)	额定风量 Rated air flow (m3/h)	初阻力 Initial resistance(Pa)	效率（级别） Efficiency (class)	滤料颜色 Liao color	袋数 pockets
CJ-M1-D1	495×295×500mm 20″×12″×20″	1000m3/h	50Pa F5   55Pa F6   60Pa F7   65Pa F8	40-50% F5   60-70% F6   75-85% F7   85-95% F8 （比色法） colorimetric	白色F5 White 绿色F6 Green 粉红F7 pink 浅黄F8 yellow	5
CJ-M1-D2	495×495×500mm 20″×20″×20″	1800m3/h				5
CJ-M1-D3	595×295×500mm 24″×12″×20″	1300m3/h				6
CJ-M1-D4	595×495×500mm 24″×20″×20″	2200m3/h				6
CJ-M1-D5	595×595×500mm 24″×24″×20″	2600m3/h				8
CJ-M1-D6	495×295×600mm 20″×12″×24″	1200m3/h				5
CJ-M1-D7	495×495×600mm 20″×20″×24″	2200m3/h				5
CJ-M1-D8	595×295×600mm 24″×12″×24″	1600m3/h				6
CJ-M1-D9	595×495×600mm 24″×20″×24″	2700m3/h				6
CJ-M1-D10	595×595×600mm 24″×24″×24″	3200m3/h				8

portant;">*可要据用户要求定制不同规格型号的过滤器

According to user requirements to customize different specifications and types of filters
