品牌:美国ALLEGRO
Supply Voltage VCC 8 V Reverse Supply:8V
Operating Temperature:–40 to 85
Output Current Source:3mA
起订:3000PCS
供应:3000PCS
发货:3天内
立即购买
FEATURES AND BENEFITS
▪ Low-noise analog signal path
▪ Device bandwidth is set via the new FILTER pin
▪ 5 µs output rise time in response to step input current
▪ 80 kHz bandwidth
▪ Total output error 1.5% at TA= 25°C
▪
Small footprint, low-profile SOIC8 package
▪
1.2 mΩ internal conductor resistance
▪ 2.1 kVRMS minimum isolation voltage from pins 1-4 to pins 5-8
▪ 5.0 V, single supply operation
▪ 66 to 185 mV/A output sensitivity
▪
Output voltage proportional to AC or DC currents
▪
Factory-trimmed for accuracy
▪ Extremely stable output offset voltage
▪ Nearly zero magnetic hysteresis
▪ Ratiometric output from supply voltag
