品牌:ON安森美/FAIRCHILD
Supply Voltage:-0.5V~+7.0
input Voltage:5.5V
Storage Temperature:-65~+150
起订:1000PCS
供应:2000PCS
发货:3天内
74LCX16245Low Voltage 16-Bit Bidirectional Transceiver with 5V Tolerant Inputs and Outputs
General Description
The LCX16245 contains sixteen non-inverting bidirectional buffers with 3-STATE outputs and is intended for bus oriented applications. The device is designed for low voltage(2.5V or 3.3V) Vcc applications with capability of interfacing to a 5V signal environment. The device is byte controlled. Each byte has separate control inputs which could be shorted together for full 16-bit operation. The T/R inputs determine the direction of data flow through the device. The OE inputs disable both the A and B ports by placing them in a high impedance state.The LCX16245 is fabricated with an advanced CMOS technology to achieve high speed operation while maintaining CMOS low power dissipation.
Features5V tolerant inputs and outputs
2.3V-3.6V Vcc specifications provided
4.5 ns tpp max (Vcc=3.3V), 20 μA lcc max
Power down high impedance inputs and outputs
Supports live insertion/withdrawal (Note 1)
+24 mA output drive (Vcc=3.0V)
Uses patented noise/EMI reduction circuitry
Latch-up performance exceeds 500 mA
ESD performance:Human body model > 2000VMachine model>200V
Also packaged in plastic Fine-Pitch Ball Grid Array (FBGA)
