品牌:进口/日照/莱钢/马钢
规格:S76*59*4.3*6.6
规格:S102*68*4.9*7.4
规格:S127*76*5.4*8.3
起订:1吨
供应:1000吨
发货:3天内
立即购买
上海1库提货地址：上海宝山区东太东路339号
山东临沂库提货地址：山东临沂河东区206国道西
山东莱芜库提货地址：莱芜区世盛库
安徽马鞍山提货地址：马钢马物仓库
广东佛山库提货地址：佛山钢铁世界
| 型号 | 理论重量(kg/m) | 截面尺寸 (mm) |
截面面积(cm²) | |||||
| W | H | B | t1 | t2 | r1 | r2 | A | |
| S75×8.5* | 8.5 | 76 | 59 | 4.3 | 6.6 | 7 | 2.1 | 10.8 |
| S75×11.2* | 11.2 | 76 | 64 | 8.9 | 6.6 | 7 | 3.8 | 14.3 |
| S100×11.5* | 11.5 | 102 | 68 | 4.9 | 7.4 | 7.5 | 4.1 | 14.5 |
| S100×14.1* | 14.1 | 102 | 71 | 8.3 | 7.4 | 7.5 | 4.8 | 18 |
| S130×15* | 15 | 127 | 76 | 5.4 | 8.3 | 7.9 | 4.9 | 18.8 |
| S150×18.6* | 18.6 | 152 | 85 | 5.9 | 9.1 | 7.9 | 4.9 | 23.6 |
| S150×25.7* | 25.7 | 152 | 91 | 11.8 | 9.1 | 8.5 | 5 | 32.7 |
| S200×27.4* | 27.4 | 203 | 102 | 6.9 | 10.8 | 8.5 | 5 | 34.8 |
| S200×34* | 34 | 203 | 106 | 11.2 | 10.8 | 9.5 | 5.2 | 43.7 |
| S250×37.8* | 37.8 | 254 | 118 | 7.9 | 12.5 | 10.5 | 6 | 48.1 |
| S250×52* | 52 | 254 | 126 | 15.1 | 12.5 | 10.5 | 6 | 66.5 |
| S310×47.3* | 47.3 | 305 | 127 | 8.9 | 13.8 | 11.5 | 6.5 | 60.3 |
| S310×52* | 52 | 305 | 129 | 10.9 | 13.8 | 11.5 | 6.5 | 66.5 |
| S310×60.7* | 60.7 | 305 | 133 | 11.7 | 16.7 | 14 | 6.5 | 77.4 |
| S310×74* | 74 | 305 | 139 | 17.4 | 16.7 | 14 | 6.5 | 94.8 |
| S380×64* | 64 | 381 | 140 | 10.4 | 15.8 | 13 | 6.5 | 81.3 |
| S380×74* | 74 | 381 | 143 | 14 | 15.8 | 13 | 7.8 | 94.8 |
| S460×81.4* | 81.4 | 457 | 152 | 11.7 | 17.6 | 14.5 | 9 | 104 |
| S460×104* | 104 | 457 | 159 | 18.1 | 17.6 | 14.5 | 9 | 133 |
| S510×98* | 98 | 508 | 159 | 12.8 | 20.2 | 15 | 9.4 | 125 |
| S510×112* | 112 | 508 | 162 | 16.1 | 20.2 | 15 | 9.4 | 142 |
| S510×128* | 128 | 516 | 179 | 16.8 | 23.4 | 15 | 9.4 | 163 |
| S510×143* | 143 | 516 | 183 | 20.3 | 23.4 | 15 | 9.4 | 182 |
| S610×119* | 119 | 610 | 178 | 12.7 | 22.1 | 15.5 | 9.6 | 152 |
| S610×134* | 134 | 610 | 181 | 15.9 | 22.1 | 15.5 | 9.6 | 171 |
| S610×149* | 149 | 610 | 184 | 18.9 | 22.1 | 15.5 | 9.6 | 189 |
| S610×158* | 158 | 622 | 200 | 15.7 | 27.7 | 15.5 | 9.6 | 201 |
| S610×180* | 180 | 622 | 204 | 20.3 | 27.7 | 15.5 | 9.6 | 230 |
