品牌:进口/日照/莱钢/马钢
规格:IPN80*42*3.9*5.9
规格:IPN100*50*4.5*6.8
规格:IPN120*58*5.1*7.7
起订:1吨
供应:1000吨
发货:3天内
立即购买
上海1库提货地址：上海宝山区东太东路339号
山东临沂库提货地址：山东临沂河东区206国道西
山东莱芜库提货地址：莱芜区世盛库
安徽马鞍山提货地址：马钢马物仓库
广东佛山库提货地址：佛山钢铁世界
| 型号 | 理论重量(kg/m) | 截面尺寸 (mm) |
截面面积(cm²) | |||||
| W | H | B | t1 | t2 | r1 | r2 | A | |
| IPN80* | 5.94 | 80 | 42 | 3.9 | 5.9 | 3.9 | 2.3 | 7.57 |
| IPN100* | 8.34 | 100 | 50 | 4.5 | 6.8 | 4.5 | 2.7 | 10.6 |
| IPN120* | 11.1 | 120 | 58 | 5.1 | 7.7 | 5.1 | 3.1 | 14.2 |
| IPN140* | 14.3 | 140 | 66 | 5.7 | 8.6 | 5.7 | 3.4 | 18.2 |
| IPN160* | 17.9 | 160 | 74 | 6.3 | 9.5 | 6.3 | 3.8 | 22.8 |
| IPN180* | 21.9 | 180 | 82 | 6.9 | 10.4 | 6.9 | 4.1 | 27.9 |
| IPN200* | 26.2 | 200 | 90 | 7.5 | 11.3 | 7.5 | 4.5 | 33.4 |
| IPN220* | 31.1 | 220 | 98 | 8.1 | 12.2 | 8.1 | 4.9 | 39.5 |
| IPN240* | 36.2 | 240 | 106 | 8.7 | 13.1 | 8.7 | 5.2 | 46.1 |
| IPN260* | 41.9 | 260 | 113 | 9.4 | 14.1 | 9.4 | 5.6 | 53.3 |
| IPN280* | 47.9 | 280 | 119 | 10.1 | 15.2 | 10.1 | 6.1 | 61 |
| IPN300* | 54.2 | 300 | 125 | 10.8 | 16.2 | 10.8 | 6.5 | 69 |
| IPN320* | 61 | 320 | 131 | 11.5 | 17.3 | 11.5 | 6.9 | 77.7 |
| IPN340* | 68 | 340 | 137 | 12.2 | 18.3 | 12.2 | 7.3 | 86.7 |
| IPN360* | 76.1 | 360 | 143 | 13 | 19.5 | 13 | 7.8 | 97 |
| IPN380* | 84 | 380 | 149 | 13.7 | 20.5 | 13.7 | 8.2 | 107 |
| IPN400* | 92.4 | 400 | 155 | 14.4 | 21.6 | 14.4 | 8.6 | 118 |
| IPN450* | 115 | 450 | 170 | 16.2 | 24.3 | 16.2 | 9.7 | 147 |
| IPN500* | 141 | 500 | 185 | 18 | 27 | 18 | 10.8 | 179 |
| IPN550* | 166 | 550 | 200 | 19 | 30 | 19 | 11.9 | 212 |
| IPN600* | 199 | 600 | 215 | 21.6 | 32.4 | 21.6 | 13 | 254 |
