品牌:日照/莱钢/马钢
规格:20*20*3
规格:25*25*3
规格:100*65*7
起订:1吨
供应:1000吨
发货:3天内
立即购买
上海1库提货地址：上海宝山区东太东路339号
山东临沂库提货地址：山东临沂河东区206国道西
山东莱芜库提货地址：莱芜区世盛库
安徽马鞍山提货地址：马钢马物仓库
广东佛山库提货地址：佛山钢铁世界
| 型号 | 理论重量(kg/m) | 截面尺寸（mm） | 截面面积(cm²) | |||
| G | H=B | t | r1 | r2 | A | |
| L20x20x3 | 0.879 | 20 | 3 | 3.5 | 1.12 | 2 |
| L25x25x3 | 1.11 | 25 | 3 | 3.5 | 1.42 | 2 |
| L25x25x4 | 1.45 | 25 | 4 | 3.5 | 1.85 | 2 |
| L30x30x3 | 1.36 | 30 | 3 | 5 | 1.74 | 2.5 |
| L30x30x4 | 1.78 | 30 | 4 | 5 | 2.27 | 2.5 |
| L35x35x4 | 2.09 | 35 | 4 | 5 | 2.67 | 2.5 |
| L40x40x4 | 2.42 | 40 | 4 | 6 | 3.08 | 3 |
| L40x40x5 | 2.97 | 40 | 5 | 6 | 3.79 | 3 |
| L45x45x4.5 | 2.74 | 45 | 4 | 7 | 3.49 | 3.5 |
| L45x45x4.5 | 3.06 | 45 | 4.5 | 7 | 3.9 | 3.5 |
| L45x45x5 | 3.38 | 45 | 5 | 7 | 4.3 | 3.5 |
| L50x50x4 | 3.06 | 50 | 4 | 7 | 3.89 | 3.5 |
| L50x50x5 | 3.77 | 50 | 5 | 7 | 4.8 | 3.5 |
| L50x50x | 4.47 | 50 | 6 | 7 | 5.69 | 3.5 |
| L50x50x7 | 5.15 | 50 | 7 | 7 | 6.56 | 3.5 |
| L55x55x5 | 4.18 | 55 | 5 | 8 | 5.32 | 4 |
| L55x55x6 | 4.95 | 55 | 6 | 8 | 6.31 | 4 |
| L60x60x4 | 3.7 | 60 | 4 | 8 | 4.71 | 4 |
| L60x60x5 | 4.57 | 60 | 5 | 8 | 5.82 | 4 |
| L60x60x6 | 5.42 | 60 | 6 | 8 | 6.91 | 4 |
| L60x60x8 | 7.09 | 60 | 8 | 8 | 9.03 | 4 |
| L70x70x6 | 6.38 | 70 | 6 | 9 | 8.13 | 4.5 |
| L70x70x7 | 7.38 | 70 | 7 | 9 | 9.4 | 4.5 |
| L70x70x8 | 8.37 | 70 | 8 | 10 | 10.7 | 5 |
| L70x70x9 | 9.32 | 70 | 9 | 9 | 11.9 | 4.5 |
| L75x75x4 | 4.65 | 75 | 4 | 9 | 5.93 | 4.5 |
| L75x75x5 | 5.76 | 75 | 5 | 9 | 7.34 | 4.5 |
| 型号 | 理论重量(kg/m) | 截面尺寸（mm） | 截面面积(cm²) | ||||
| W | h | b | t | r1 | r2 | A | |
| L100x65x7 | 8.77 | 100 | 65 | 7 | 10 | 5 | 11.2 |
| L100x65x8 | 9.94 | 100 | 65 | 8 | 10 | 5 | 12.7 |
| L100x65x9 | 11.1 | 100 | 65 | 9 | 10 | 5 | 14.1 |
| L100x65x10 | 12.3 | 100 | 65 | 10 | 10 | 5 | 15.6 |
| L100x65x12 | 14.5 | 100 | 65 | 12 | 10 | 5 | 18.5 |
| L110x70x10 | 13.4 | 110 | 70 | 10 | 10 | 5 | 17.1 |
| L110x70x12 | 15.9 | 110 | 70 | 12 | 10 | 5 | 20.3 |
| L120x80x8 | 12.2 | 120 | 80 | 8 | 11 | 5.5 | 15.5 |
| L120x80x10 | 15 | 120 | 80 | 10 | 11 | 5.5 | 19.1 |
| L120x80x12 | 17.8 | 120 | 80 | 12 | 11 | 5.5 | 22.7 |
| L125x75x8 | 12.2 | 125 | 75 | 8 | 11 | 5.5 | 15.5 |
| L125x75x9 | 13.6 | 125 | 75 | 9 | 11 | 5.5 | 17.3 |
| L125x75x12 | 15 | 125 | 75 | 10 | 11 | 5.5 | 19.1 |
| L125x75x12 | 17.8 | 125 | 75 | 12 | 11 | 5.5 | 22.7 |
| L130x90x10 | 16.6 | 130 | 90 | 10 | 11 | 5 | 21.2 |
| L130x90x12 | 19.7 | 130 | 90 | 12 | 12 | 6 | 25.1 |
| L130x90x14 | 22.8 | 130 | 90 | 14 | 11 | 5 | 29 |
| L140x90x8 | 14 | 140 | 90 | 8 | 11 | 5.5 | 17.9 |
| L140x90x10 | 17.4 | 140 | 90 | 10 | 11 | 5.5 | 22.1 |
| L140x90x12 | 20.6 | 140 | 90 | 12 | 11 | 5.5 | 26.3 |
| L140x90x14 | 23.8 | 140 | 90 | 14 | 11 | 5.5 | 30.4 |
| L150x75x9 | 15.4 | 150 | 75 | 9 | 12 | 6 | 19.6 |
